AC Multimeter with Alarm
Click to enlarge

BLUE SEA AC Multimeter with Alarm / BS-8247

Original price was: $719.04.Current price is: $677.16. inc GST

or 4 payments of $169.29 with Wizit learn more

BLUE SEA AC Multimeter with Alarm / BS-8247

Pay by  Add to cart.

Out of Stock

ENQUIRY!
Add to wishlist
Compare
SKU: BS-8247 Category:

UPC:

Condition:  New

Out of Stock

NOTE - Please call us to check availability & leadtimes prior to ordering as not all Blue Seas items are carried in stock.

Description

Description

BLUE SEA AC Multimeter with Alarm / BS-8247

HIGHLIGHTS

  • Displays amperage from 0 to 150 Amps.
  • Displays voltage from 80 to 270 Volts.
  • Displays power from 0 to 35 Kilowatts.
  • Displays frequency from 40 to 90 Hertz.
  • High and low voltage and high amperage alarms, both audio and visual.
  • 3 levels of display brightness.
  • Programmable sleep mode blanks display for power conservation.
  • Splashproof front.
  • Includes current transformer.

NOTE For 120 & 240 Volt AC single phase systems.

SPECIFICATIONS

  • PART NUMBER: BS-8247
  • METER: CURRENT, FREQUENCY, POWER, VOLTAGE
  • INPUT VOLTAGE: 80-249V
  • DISPLAY CHARACTER SIZE: 0.5625mm (14.29″)
  • MAXIMUM POWER CONSUMPTION: 1 Watt
  • SLEEP MODE: PROGRAMMABLE
  • ALARMS: HIGH AND LOW VOLTAGE, HIGH CURRENT
  • WEIGHT 0.35kg (0.78 lb)

VOLTAGE MEASUREMENT

  • RANGE: 80-249V AC
  • RESOLUTION: 0.1V AC

CURRENT MEASUREMENT

  • CURRENT TRANSFORMER: 150A/50mA
  • RANGE 1 (RESOLUTION 0.01A): 0.00–9.99A AC (RMS)
  • RANGE 2 (RESOLUTION 0.1A): 10.0–150.0A AC (RMS)

FREQUENCY MEASUREMENT

  • RANGE: 40–90Hz
  • RESOLUTION: 0.1Hz

POWER MEASUREMENT

  • RANGE 1 (RESOLUTION 10W): 0-9990W
  • RANGE 2 (RESOLUTION 0.1W): 10-45kW
