Description
BLUE SEA ANL Fuse Block with Insulating Cover – 35 to 300A / BS-5005
HIGHLIGHTS
- Accepts 5/16″ (M8) ring terminals.
- For use on systems up to 32 Volts DC.
- Swing out design allows replacement of the fuse without removing fasteners.
- Stainless steel studs provide resistance to corrosion and high torquing for excellent electrical contact.
- UL 94-V0 base resists high heat.
- Insert molded studs ensure secure fuse mounting.
- Insulating cover satisfies ABYC/USCG requirements.
- Cover breakouts allow wire access in any direction.
- Fuse sold separately.
SPECIFICATIONS
- PART NUMBER: BS-5005
- MAXIMUM VOLTAGE: 32V DC
- BASE MATERIAL: Reinforced Polycarbonate
- FUSE MOUNTING BLOCKS: Tin-Plated Copper
- MAXIMUM CABLE SIZE: 2/0 AWG
- MAXIMUM TORQUE: 110 in-lb (12.43 Nm)
- TERMINAL STUD SIZE: 5/16″ – 18 (M8)
- WEIGHT: 0.16 kg (0.35 lb)
OVERALL DIMENSIONS (LENGTH x WIDTH x HEIGHT): 99mm x 184mm x 45mm
