Description
BLUE SEA HD-Series Heavy Duty On-Off Battery Switch / BS-3000
Switches a single battery to a single load group
HIGHLIGHTS
- Ignition protected—safe for installation aboard gasoline powered boats.
- Case design allows surface or rear panel mounting.
- Accepts two 4/0 AWG (95mm²) battery cables.
SPECIFICATIONS
- PART NUMBER: BS-3000
- SWITCH TYPE: Single Circuit ON-OFF
- COLOR: GREY
- SWITCH POSITIONS: 2
- BATTERY COMBINE: NO
- ALTERNATOR FIELD DISCONNECT: NO
- MAXIMUM VOLTAGE: 32V DC
- TERMINAL STUD TORQUE: 220 in-lb (24.86 Nm)
- CONTINUOUS RATING: 600A
- INTERMITTENT RATING: 900A (5 min)
- CRANKING RATING 30 SEC: 1750A
- BATTERY INPUTS: 1
- CABLE CLEARANCE FOR 4/0 AWG CABLES: 1.10″ (27.94 mm)
- CABLE QUANTITY TO MEET RATINGS: Two Cables
- CABLE SIZE TO MEET RATINGS: 4/0 AWG (120mm²)
- MOUNTING HOLES: Accept 1/4″ (M6) Screw
- TERMINAL STUD SIZE: 1/2″ (M12)
- WEIGHT: 1.30 lb (0.59 kg)
OVERALL DIMENSIONS (LENGTH x WIDTH x HEIGHT): 85mm x 162mm x 218mm
