BLUE SEA SYSTEMS Monitor Tank Sender – Diesel, Water, Waste / BS-1810
Meters with backlighting for low light conditions.
HIGHLIGHTS
- Accurate – used with the Vessel Systems Monitor VSM 422 PN 1800—can be precisely calibrated for each tank*
- Reliable – SSI Technologies, Inc. Fluid-Trac is non-contacting eliminating any mechanical moving parts that can wear and cause intermittent or complete signal loss
- Digital Filtering – Eliminates errors due to liquids sloshing in mobile tanks
Limitations and considerations for mounting the ultrasonic tank senders:
- Senders are calibrated to the VSM 422 and M2 Meters and will not function with other monitors.
- Senders must be mounted 4″ or greater distance from a tank side or baffle.
- Tank floor must not be sloped.
- Tanks must not be deeper than 32″.
- Sender must be mounted perpendicular to the surface of the liquid.
- The sender negative connection should be connected as directly as possible to the main negative bus.
SPECIFICATIONS
- PART NUMBER: BS-1810
- OPERATING CURRENT: 40mA @ 12V, 45mA @ 24V
- SUPPLY VOLTAGE: 10-32V DC
- WEIGHT: 0.25 lb (0.11 kg)
