Description
Hinge Friction / Torque Top Flush Mount – 316 Stainless Steel – 38mm x 76mm / SAW-38622
HIGHLIGHTS
- Cast 316G stainless steel.
- Available in two styles – surface mount with protruding hinge pin or with the hinge pin recessed to mount flat with the deck.
- Constant torque – 30kgf+/-15%.
- Solid stainless steel pin.
- 12mm barrel height.
- Holds light hatch or cover in place.
SPECIFICATIONS
- LENGTH: 38mm
- WIDTH: 76mm
- TYPE: RECESSED MOUNT
- SPLIT: 38mm/38mm
- LEAF THICKNESS: 3mm
- NO. MOUNT HOLES: 6
- MOUNT SCREWS: 4mm c/s
- This product is sold individually.
See complete specifications of all hinges in the table below.
| PART NUMBER | PRODUCT TYPE | LENGTH x WIDTH | SPLIT | LEAF THICKNESS | NO. MOUNT HOLES | MOUNT SCREWS |
| 38620 | SURFACE MOUNT | 38mm x 76mm | 38mm / 38mm | 3mm | 6 | 4 c/s |
| 38622 | RECESSED MOUNT | 38mm x 76mm | 38mm / 38mm | 3mm | 6 | 4 c/s |
| 38624 | SURFACE MOUNT | 38mm x 38mm | 19mm / 19mm | 3mm | 4 | 4 c/s |
| 38626 | RECESSED MOUNT | 38mm x 38mm | 19mm / 19mm | 3mm | 4 | 4 c/s |
| 38628 | SURFACE MOUNT | 76mm x 50mm | 25mm / 25mm | 3mm | 6 | 5 c/s |
| 38630 | RECESSED MOUNT | 76mm x 50mm | 25mm / 25mm | 3mm | 6 | 5 c/s |
| 38632 | SURFACE MOUNT | 38mm x 66mm | 38mm / 28mm | 3mm | 5 | 4 c/s |
| 38634 | RECESSED MOUNT | 38mm x 66mm | 38mm / 28mm | 3mm | 5 | 4 c/s |
