Jabsco Heavy Duty Composite Pumps 2″ Flanged Ports 52220-0013
2″ heavy duty flexible impeller pumps with flanged ports.
Spaced bearings allow faster running speeds and mechanical seal offers long life and reliability for heavy duty commercial applications.
Should not be run dry.
Self priming up to 4.5 metres vertical lift. Supplied standard with neoprene impeller.
2″ pump : 276L x 170W x 146mm H. Flow 22,000 LPH at 3M head @ 1500 RPM.
J50-130 1 1/2″ flanged 52220-0011 J50-134 2″ flanged 52270-0011
J53-513 Impeller – neoprene 17935-0001 J53-517 Impeller – neo 17936-0001
J53-520 Impeller – nitrile 836-0003 J53-536 Impeller – nitrile 6760-0003
J55-005 Service kit neoprene SK407-0011 J55-006 Service kit -neo SK408-0011
J55-008 Service kit nitrile SK407-0003 J55-211 Gasket 816-0000
J55-227 Seal 21849 / 6408 J55-227 Seal 21849 / 6408
J55-222 Oil seal SP2701-54 J55-250 Shaft 52277-0000
J55-228 Bearing SP2601-0458
J55-249 Shaft 52227-0000
