Jabsco Pump Par-Max 1 PLUS 12 volt 42630-2992 3.8LPM OEM Version

Description

Jabsco Water Pressure Pump ParMax 1 PLUS 3.8LPM 12 volt 42630-2992 – OEM No Retail Packaging

This pump is an OEM Bulk pump (no retail packaging).

This pump is a lot lower priced than the retail packaged pump. It is exactly the same as the packaged pump – except that it is supplied with a pair of quick connect plug-in ports to suit 10mm (3/8″) standard hose &also a pair of John Guest quick connect plug-in ports to suit John Guest 1/4″ tubing.

We will provide generic packaging for shipping purposes. These pumps are usually used by boat builders that dont want to waste money on retail packaging.

Flow rate: 3.8 Litres/min (0.84 gallons/min)

Self-priming from dry up to 1.8m (6ft)

Demand (pressure switch shut-off)

Sealed motor and pressure switch, providing years of dependable reliability

Jabsco Diaphragm pumps provide dependable run dry capabilities, extending the life of the pump Built in thermal protector, prevents overheating to protect the pump from damage.

Quick Disconnect Ports allow for quick cleaning and easy hose replacement in seconds

• Low amp draw, ideal for battery powered applications.
• Optional faucet with tubing and fittings model to complete the water delivery system on your vessel.

This NEW Jabsco design with an IP (Ingress Protection) rated cover and quick fit ports improves the installation process and follows 50 years of innovative Jabsco design. With on demand (pressure switch shut-off) and made from a robust material selection, suitable for handling a broad range of applications these low flow pumps meet the markets variable demands. Ideal a caravan, boat or RV’s galley sink requirements. Approx 4 litres a minute will not waste precious stored water. Jabsco Diaphragm pumps provide dependable run dry capabilities, extending the life of the pump.

Pressure Switch Specifications

• Pressure Setting: 35 PSI (2.4 bar)

Connection Ports

• Plug-in Ports:
  • 2 x ports for 10mm (3/8″) standard hose
  • 2 x John Guest quick connect ports for 1/4″ tubing

Electrical Specifications

• Voltage: 12V DC
• Amp Draw: 4 Amps
• Fuse Size: 4 Amp

Motor Specifications

• Type: Permanent Magnet, Thermally Protected, Intermittent Duty

Protection Class

• Protection Class: IPX4

Performance Specifications

• Flow Rate: 3.8 litres per minute (1 gallon per minute) at open flow
• Automatic Pressure Switch Cut Off: Up to 35 PSI
• Self Priming Capability: Up to 1.8 metres (6 ft)

Temperature Range

• Operating Temperature: 4°C to 43°C (max)

Additional Features

• Thermal Overload Protection: Built-in
• Mounting: Vibration & noise reducing rubber mountings
• Quick Connect/Disconnect Ports: Included
• Adaptors Provided: For 12mm (1/2″) hose
• Low Amp Draw: Ideal for battery powered applications
