VETUS Battery Selector Switch Type / Continuous 175A / Interval 300A / ACCUSCH

Description

VETUS Battery Selector Switch Type / Continuous 175A / Interval 300A / ACCUSCH

This product is a famous VETUS battery selector switch with a multi-functional component and a reliable sturdy rotary series switch.

FEATURES

• From the OFF position, the following batteries may be “switched on” – in accordance with the switch pattern: Battery 1 only, Battery 1 plus Battery 2, Battery 2 only.
• The switch enables usage and charging of the batteries, both individually and in parallel connection.
• This product is Kema and underwriters laboratories approved.
• This comes with a red locking button – indicating and locking the switch position for convenience.

OPERATION

• If a VETUS battery selector switch is fitted, you have an option to choose which battery (or batteries) will supply which service(s).
• One of 2 batteries is used for starting the engine. But if that battery is nearly discharged (or defective), the other battery can be used for rescue. The selector switch will prove to be invaluable on such situation.
• It is possible to draw power for the starter motor from both batteries, if the switch is set in position: “Both”.
• The switch will “make before break” and so battery selection is possible even with the engine running (do not go through the “off” position).

Using a VETUS battery selector switch, the starter battery and the domestic battery may be used and charged, as desired.

SPECIFICATIONS

DIMENSIONS: 135(H) x 135(W) x 75mm(D)

VOLT CAPACITY: 6-12-24 or 32 Volt: CONTINUOUS: 175A – INTERVAL: 300A

OVERALL PRODUCT SIZE (L/W/H): 144mm x 144mm x 85mm

NOTE – Please call us to check availability & leadtimes prior to ordering as not all Vetus items are carried in stock.

Rotary battery switch 175A continuous 85x144x144
